Product Overview
The 32-Channel HD Digital Video Recorder is a powerful surveillance solution featuring the H.265 video codec for efficient compression and high-quality video. It supports a maximum input bandwidth of 16Mbps and is compatible with AHD, TVI, CVI, Analog 960H, and IP cameras, offering up to 5MP Lite resolution for both preview and playback. This DVR can accommodate up to four hard drives, each with a capacity of 14TB, providing a total storage capacity of up to 56TB. It offers full network remote viewing capabilities via CMS, IE, Firefox, Chrome, and Mac Safari, with no limitations on adding devices to CMS and a maximum of 32 channels for preview. The DVR supports P2P QR code scanning for easy mobile app connection through AVY Mobile One, and allows saving pictures and videos to Dropbox or a user-built FTP server. With VGA and HDMI outputs supporting up to 4K resolution, this DVR can handle a total of 36 channels, including 32 analog channels and 4 additional IP channels, making it an ideal choice for comprehensive video surveillance needs.
General Information
Name : AVYCON AVR-DSV532H 32-Channel HD Digital Video Recorder, 16Mbps , AVYCON
Category : Hybrid Video Recorders
UPC Code : 608011418601
Country of Origin : China. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : BX-DSV532H
Bandwidth : 16 Mbps
Brand Name : AVYCON
Manufacturer Part Number : AVR-DSV532H
Product Type : Digital Video Recorder
Technical Information
Effective Camera Resolution : 5MP
Maximum Frame Rate : 960 fps
Number of Channels : 36
Video Formats : H.264, H.265
Display & Graphics
Maximum Video Resolution : 3840 x 2160
Interfaces/Ports
Number of HDMI Outputs : 1
Number of USB Ports : 2
Number of VGA Outputs : 1
Power Description
Input Voltage : 12V DC
Maximum Power Consumption : 21W
Video
Maximum Resolution : 2592 x 1944
Miscellaneous
Country of Origin : CN
