Product Overview
Wisenet X powered by Wisenet 5 network indoor vandal dome camera, 2MP, Full HD(1080p) @60fps WDR off or @30fps WDR on, Motorized Vari-Focal Lens 4.3x (2.8~12mm) (119.5°~27.9°), H.265/H.264/MJPEG, WiseStream II compression technology, 150dB WDR, USB port for easy installation, Advanced video analytics and sound classification, True D/N, Dual SD card, Hallway view, HLC, Defog detection with simple focus, DIS , 12VDC/PoE, IK08
General Information
Name : Hanwha XND-6080V X-Series 2MP Indoor Vandal Dome Camera, 2.8-12mm Varifocal Lens, Ivory , Hanwha Vision
Category : Dome Cameras
UPC Code : 8801089100849
Country of Origin : China. Country of origin is subject to change.
Specifications
General Information
ADI Part Number : SQ-XND6080V
Brand Name : Hanwha Vision
Manufacturer : Hanwha Vision
Manufacturer Part Number : XND-6080V
Product Model : XND-6080V
Product Name : 2MP Network Indoor Dome Camera
Product Series : X
Product Type : Dome Camera
Technical Information
Field of View : H: 119.5°-27.9°, V: 62.8°-15.7°, D: 142.1°-32.0°
Maximum Aperture : F1.4
Maximum Frame Rate : 60fps
Minimum Focal Length : 2.8mm
Optical Zoom : 4.3x
Video Formats : H.264, H.265, MJPEG, MPEG-4
Camera
Image Sensor Type : CMOS
Wide Dynamic Range : Yes
Certifications
NDAA Compliant : Yes
Display & Graphics
Maximum Video Resolution : 1945 x 1109
Environmental Conditions
Maximum Operating Temperature : 131°F
Minimum Operating Temperature : 14°F
Operating Humidity : 90% RH
Exposure
Longest Shutter Speed : 2 Second
Minimum Illumination : 0.015 Lux
Shortest Shutter Speed : 1/12000 Second
Interfaces/Ports
Network (RJ-45) : Yes
Lens
Focal Length : 2.8-12 mm
Lens Included : Yes
Maximum Focal Length : 12 mm
Minimum Aperture : f/1.4
Network & Communication
Remote Management : Yes
Physical Characteristics
Color : Ivory
Durability : Impact Resistant
Form Factor : Dome
Height : 4.4"
Power Description
Input Voltage : 12V DC
Product Information
Diameter : 5.54"
Storage
Recording Formats : Full HD
Storage Type : Memory Card
Warranty
Limited Warranty : 3-Year
Miscellaneous
Country of Origin : CN|KR
Features : Alarm Triggering, Day/Night, Defog, Digital Image Stabilization, Digital Noise Reduction, Gain Control, Motion Detection, Privacy Masking, White Balance, WIDE DYNAMIC RANGE
Impact Protection Rating : IK08
Indoor/Outdoor : Indoor
